TITAN 34 ton side tippers semi trailer is often combined with construction machinery such as excavators, loaders, and it is mainly used for loading, unloading and transporting earthwork, gravel and bulk materials
The whole TITAN 34 ton side tippers semi trailer can be turned left and right. Compared with the dump trailer, it has the advantages of high safety factor, more cargo, and lower price. The loading capacity of the side tipper
semi trailer is 34 ton for transporting sand or small stones or rocks. The 34 ton side tippers also could be produced as 2/3/4/5 Axles according to customers actual needs. The Color could bed painted as customers request.
Tri Axle 34 Ton Side Tippers Semi Trailer for Sale Manufacturers
Tri Axle 34 Ton Side Tippers Semi Trailer for Sale Manufacturers
Tri Axle 34 Ton Side Tippers Semi Trailer for Sale Manufacturers
Brand: TITAN side tipper trailers
Chassis: Heavy duty and extra durability designed I beam
Axle: 3 axles
Tire: 12 units
Loading capacity: 34 tons
Hydraulic system: HYVA cylinder
Suspension: Mechanical suspension
Lifting system: Side lifting
Kingpin: 3.5’’ bolt - in king pin 90
Landing gear: JOST
Braking system: WABCO
Accessories: One standard tool box , one rocker handle , one Shaft wrench
Valve: WABCO valve (specially intended for oversea market)
ABS: Optional
Light: LED light (specially intended for oversea market)
Voltage: 24V
Socket(Receptacle): 7-pin Socket (for 7 wire harness)
Tool Box: 1m x 0.5m x 0.5m (The tool box contains 1 tire spanner, 1 gudgeon sleeve and 1 cranking bar. Its size can be tailored to suit your needs)
Painting: Sandblasted, anti-rust chassis surface is available with 1 layer of anticorrosive primer and 2 layers of top coats
1. Double-plate main beam
TITAN adopts double-plate main beam for 34 ton side tipper trailers; the main beam is designed with double plates, which have more carrying capacity and not easy to be damaged
2. Hydraulic cylinder
TITAN adopts famous brand HYVA cylinder. The heavy-duty cylinder with a wider diameter, stronger lifting capacity and higher height, which makes the lifting more stable and does not easy to roll over.
3. Steel material
The 34 ton side tipper trailer is using HG60 high-strength steel, high hardness of steel, can effectively prevent collision and avoid deformation of the cargo box.
Through these videos, you can learn about different types of side tipper trailers, as well as the process, testing, packaging and customer feedback, etc.
